We propose the realization of an autonomous factory that continues to evolve autonomously.
Details of verifications and demonstrations
Proposal of highly functional and efficient production using a production line that imitates the customer’s production site
1. Device/smartphone line
- Micro component mounting (0201 components onward)
- Densified mounting
- High-quality manufacturing (M2M link system)
- Improved productivity (automatic changeover using iLNB)
2. Automotive/industrial device line
- Large/tall component mounting
- High-quality manufacturing (M2M link system)
- Improved productivity (automatic changeover using iLNB)
- Traceability
Our staff will work with you to solve problems (printing to reflow, mounting analysis, and production technical support)
- Verification and demonstration using demonstration/customer PCBs, components, and bonding materials
(Printing, pickup, recognition, placement, reflow, and bonding quality) - Optimization of printing conditions
- Optimization of pickup and placement conditions
- Takt verification
- Automation and labor-saving
- Void observation using an X-ray inspection device
- Confirmation of printing accuracy, solder volume, and solder shape of printed solder by inspection machine. And evaluation of normal distribution.
- Various seminars on mounting methods, printing methods, etc.
Various evaluation equipments to meet the various needs of customers
Various equipments are available for visualization of solder/component conditions and changes in printing, mounting, and joining.
[Printing] Spiral solder viscometer
[Printing] Micro spiral viscometer
[Printing] Solder agitator
[Printing] Rheometer
[Printing] Mask tension gauge
[Printing] Shape analysis laser microscope
[Mounting] High-precision image measurement system
[Mounting] Mounting accuracy and load measuring instrument
[Printing/Mounting] High-speed microscope
[Printing/Mounting] High-definition 3D printer
[Joining] Reflow simulator
[Joining] Automatic grinder with individual loading method
Digital microscope
3D Shape measuring machine
Laser elemental analyzer
Online verifications and demonstrations
Online verifications and demonstrations that use the Internet are provided. Although you cannot touch the actual machines, you can communicate interactively with us by asking and answering questions, so you can understand more about the product than simply looking at a catalog or video. It is also possible to connect to multiple locations at the same time from within the company. It is easy to participate even from afar and less time consuming, so please take advantage of this service!
Introduction of each area
The center reproduces the SMT site in the image of the customer's SMT floor, with not only our products but also machines and devices from alliance partners. We offer concrete proposals to solve problems in each area.
Production planning area = Central control room
In this area, aiming for intelligent human decision making, visualization of the mounting floor and resource-aware production simulation of the entire mounting area directs efficient production execution. Also, solutions for manpower saving, such as remote operation, are introduced.
SMT area
In this area, in addition to checking actual equipment when selecting equipment, Panasonic mounting equipment, inspection machines, and reflow furnaces are also connected to the line, allowing production verification using actual materials. In addition, automation functions aimed at automating human work are introduced.
Material preparation area
This area manages the receiving and shipping of materials needed for production and performs picking operations based on instructions from the materials management system.
Outside setup area
In this area, the picked parts are linked to the production plan and set on the feeder/bulk change carts according to the navigation system instructions.
Maintenance area
In this area, we introduce automatic maintenance equipment for mounting heads, nozzles, and feeders, which are the key to producing good products. We propose the construction of a system for manufacturing with good heads, good feeders, and good nozzles.
Display area
A variety of products is always on display in this area. We provide total system solutions by combining the most appropriate solutions and products while listening to your needs.
- PCB: Demonstration PCB (devices, smartphones, vehicles, and computers)
- Component: 0201 to large odd-form components for vehicles
- Bonding materials: Solder and adhesive
- Other: Various idea products, etc.
* Electronic Materials Laboratory
The Fukuoka Technical Center has an electronic materials laboratory that can develop, formulate, and evaluate bonding methods and newly required adhesives, die-bonding pastes, and fluxes.
Displayed machines
| Mounting machines | Modular Placement Machine NPM-GW |
Modular Placement Machine NPM-GH |
Modular Placement Machine NPM-DX |
Modular Placement Machine NPM-WX |
|---|---|---|---|---|
| Production Modular NPM-W2 |
Production Modular NPM-TT2 |
Production Modular NPM-D3A |
Modular Placement Machine VM Series |
|
| Modular Placement Machine AM100 |
/products-services/fa_products_mounting-related/lineup/am100
| Solder inspection devices | Koh Young（Meister S：5um) CKD (VP6000LD-V: 15 μm, VP6000M-V: 8 μm) PARMI (SIGMAX: 5 μm) |
|---|---|
| Component visual inspection devices | SAKI（３Di－LD3：8μm) PARMI（Xceed：７μm） |
| X-ray inspection devices | OMRON (VT-X750: CT type, 6 μm variable) |
| Reflow oven | Senju Metal (SNR-840GT) |
| Other | Malcom (High-temperature Observation Oven) Nikon (NEXIV Video Measuring Systems) Keyence (Various microscopes) |
Location
4-1-62 Minoshima, Hakata-ku, Fukuoka City, Fukuoka 812-8531
Kofu Technical Room
Introduction to the Kofu Technical Room
We offer demonstration and evaluation services for individual equipment such as mounting machines and Screen Printer.
Please take advantage of this service.
Details of verifications and demonstrations
Our staff will work with you to solve problems
(Print evaluation, mounting analysis, and production technical support)
- Verification and demonstration using demonstration/customer PCBs, components
(Printing, pickup, recognition, placement) - Optimization of printing conditions
- Optimization of pickup and placement conditions
- Takt verification
- Confirmation of printing accuracy, solder volume, and solder shape of printed solder by inspection machine. And evaluation of normal distribution.
Latest Screen Printer NPM-GP/L
Latest Placement Machine: NPM-GH
Latest Placement Machine: NPM-GW
Modular Placement Machine: NPM-WX
Odd-form Component Insertion Machine: NPM-VF
The Kofu Technical Room also offers proof-of-concept testing for the NPM-VF odd-form component insertion machine.
-
Automation feasibility testing with demo PCBs and components, or with customer PCBs and components.
-
Optimization of insertion tools (chucks, nozzles, etc.)
-
Optimization of component supply packaging to resolve packaging issues for automation.
-
Takt verification
NPM-VF Optional Specifications Available for Verification at the Kofu Technical Room
-
Stackable stick feeder (with Component Verification function)
-
Radial tape feeder
-
Anvil Unit
-
Body Chuck
Various evaluation equipment
Various equipments are available for visualization of solder/component conditions and changes in printing, mounting, and joining.
[Printing/ Mounting] High-speed microscope
Digital microscope
3D Shape measuring machine
[Mounting] High-precision image measurement system (scheduled for introduction in FY2026)
[Printing] Solder inspection devices (scheduled for introduction in FY2026)
Displayed machines
| Printers | Screen Printer NPM-GP/L |
|---|
| Mounting machines | Modular Placement Machine NPM-GW |
Modular Placement Machine NPM-GH |
Modular Placement Machine NPM-DX |
Modular Placement Machine NPM-WX |
|---|---|---|---|---|
| Production Modular NPM-D3A |
| Insertion machines | Odd-form Component Insertion Machine NPM-VF |
|---|
| Solder inspection devices | CKD（VP9000) |
|---|---|
| Others | Nikon (NEXIV image measuring device) Keyence (various microscopes) |
Location
1375 Kamisukiawara, Showa-cho, Nakakoma-gun, Yamanashi 409-3895
