Thyristor TIG Welding Machine
WP4 / WS4 Series
Overview
WP4 / WS4 Series
General Catalog of TIG Welding Machines
* In addition to this product (welding power source), a torch and gas regulator are required for welding.
Key functions
-
One unit serves seven purposes (WP) for applications to a wide range of welding conditions
-
Achieves high-quality welding through pulse welding (WP)
Issues
Use for a wide range of welding conditions
WP4 is the only model that supports AC manual welding. It also supports various other welding processes and can be applied to a wide range of welding conditions.
Strengths and Features
One unit serves seven purposes for applications to a wide range of welding conditions
One unit supports a wide range of welding processes. Switching between welding processes can be done with a single-touch operation. WP4 is equipped with pulse welding functions.
Achieves high-quality welding through pulse welding
The WP4 series is equipped with pulse welding functions. This welding process is effective for welding of thin plates, which tend to burn through, penetration welding, welding of aluminum, which has good thermal conductivity, and welding of aluminum alloy materials.
Option List
Welding torch
Remote control unit
●YC-304URW
Included with the welding power source
Gas regulator
●YX-251A
For argon gas welding
Water-cooling option
● YX-09KGC1 (standard type)/YX-09KGB1 (insulation type)
Specifications
| Model number | YC-300WP4 | YC-300WS4 | ||
|---|---|---|---|---|
| Rated input voltage | V | 200 AC (allowable fluctuation range: 180 to 220) | ||
| Number of phases, rated frequency | ー | Single-phase, 50 / 60 Hz | ||
| Rated input | ー | 26 kVA (17 kW) | ||
| Maximum open circuit voltage | V | 80 | ||
| Rated duty cycle (10-minute cycle) |
% | 40 | ||
| Output current adjustment range | DC TIG, DC manual welding | A | 5 to 300 | |
| AC TIG, AC manual welding | 20 to 300 | |||
| Applicable welding process | ー | DC TIG, AC TIG, DC manual welding, AC manual welding | ||
| Applicable shielding gas | ー | Ar: 100% | ||
| Up-slope time | s (seconds) | 0.1 to 6 | ||
| Down-slope time | s (seconds) | 0.2 to 10 | ||
| Pre-flow time | s (seconds) | 0.3 | ||
| Post-flow time | s (seconds) | 5 to 25 | ||
| Arc spot time | s (seconds) | 0.5 to 5 | ||
| Pulse frequency | Hz | 0.5 to 10 | ー | |
| Input power supply terminal | ー | Cable connection (M6 bolt fixing) | ||
| Output terminal | ー | Copper plate terminal (with M8 bolt) | ||
| External dimensions (width x depth x height) |
ー | 465 × 617 × 846 | ||
| Mass | kg | 150 | ||
*1: Please check the catalog for the applicable diameters of solid wires and FCWs.
*2: The depth dimension does not include the input power supply terminal cover on the rear panel.
* With a 3 m long gas hose and remote control unit
● View the required power supply capacity and cable thickness data
